Detailed Description

Hydro Edge Air-to-Water Heat Exchangers are ideal for food processing plants, agricultural irrigation, waste-water treatment, automotive plants, flour milling and mining operations where water is readily available onsite.
Thermal Edge 5-year warranty logo

Hydro Edge logo

3690 BTUH air to water heat exchangers for 12″ deep enclosures
(@ 95°F Enclosure & 50°F Water Temperatures @ 2 GPM)

UL CE logo



Key Design Features

  • Protection from outdoor contaminants with a closed loop design.
  • Constant elimination of condensate
  • Easy maintenance with a filter free design
  • Flexible application with the narrow body style fitting 12” deep enclosures.
  • Eliminates water and corrosion buildup in washdown applications with
    a sloped roof design and seam welded shroud.
  • Ruggedly designed for manufacturing environments in powder coated steel
    or corrosion resistant stainless steel
  • Maintains UL Tested NEMA Type 12, 4, and 4X
  • Ambient operating temperature: 34°F – 140°F
  • Overall dimensions: 19.7” H x 11.8” W x 5” D
  • Air flow rate: 129 CFM @ 0 Static Pressure
  • Unit weight: 21.4 lbs.

Options:

  • Integrated Digital Temperature Controller
  • Solenoid Water Valve
  • Water Leak Detection Switch
  • Dry Contact Alarm
  • Open Door Kill Switch
  • Corrosive Environment Package
  • 316 Stainless Steel Housing
  • Mill Finish Aluminum Housing
  • Enclosure Mounted Controller
  • Remote Monitoring Options
  • UL Power Cord

Accessories:

  • Water Supply Shutoff Valves

Variations

  1. A2W301212 / 115 VAC / UL Type 12

    BTU/H: 3690 Material: Powder coated steel Volt./Hz.: 115/50-60 Running Amps: 0.37 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0

  2. A2W301204 / 115 VAC / UL Type 4

    BTU/H: 3690 Material: Powder coated steel Volt./Hz.: 115/50-60 Running Amps: 0.37 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0

  3. A2W30124X / 115 VAC / UL Type 4X

    BTU/H: 3690 Material: Stainless Steel Volt./Hz.: 115/50-60 Running Amps: 0.37 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0

  4. A2W302312 / 230 VAC / UL Type 12

    BTU/H: 3690 Material: Powder coated steel Volt./Hz.: 230/50-60 Running Amps: 0.23 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0

  5. A2W302304 / 230 VAC / UL Type 4

    BTU/H: 3690 Material: Powder coated steel Volt./Hz.: 230/50-60 Running Amps: 0.23 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0

  6. A2W30234X / 230 VAC / UL Type 4X

    BTU/H: 3690 Material: Stainless Steel Volt./Hz.: 230/50-60 Running Amps: 0.23 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0

  7. A2W304812 / 460 VAC / UL Type 12

    BTU/H: 3690 Material: Powder coated steel Volt./Hz.: 460/50-60 Running Amps: 0.12 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0

  8. A2W304804 / 460 VAC / UL Type 4

    BTU/H: 3690 Material: Powder coated steel Volt./Hz.: 460/50-60 Running Amps: 0.12 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0

  9. A2W30484X / 460 VAC / UL Type 4X

    BTU/H: 3690 Material: Stainless Steel Volt./Hz.: 460/50-60 Running Amps: 0.12 Max. Ambient Temperature: 140°F H X W x D: 19.7 x 11.8 x 5" Unit Weight (lbs): 21.4 Shipping Weight (lbs): 26.0
